Microwave chemical reactors, also known as microwave synthesis instruments or microwave-assisted synthesis systems, are advanced experimental and production equipment that utilize microwave energy as a heat source to directly heat and drive chemical reaction systems.
Unlike traditional external conduction heating methods, such as oil baths or electric heaters, microwave reactors use electromagnetic waves to directly interact with the molecules of the substance, thereby achieving bulk-phase heating. This unique heating method overcomes the physical limitations of heat transfer and can produce significant “microwave non-thermal effects” (controversial but observed phenomena) and “thermal effects,” resulting in reaction rates that are hundreds or even thousands of times faster, and reaction times that are reduced from several hours to mere minutes. It is a revolutionary tool in modern green chemistry, drug development, materials science, and organic synthesis, and is hailed as an “accelerator” for chemical synthesis.
Zhuocheng instrument microwave chemical reactor parameter table | |||
product model | WBFY-201 | WBFY-205 | MCR-3 |
Rated power consumption (W) | 1100 | 1100 | 1300 |
Maximum input current (A) | 7.8 | 7.8 | 8.0 |
Rated output power (W) | 750 | 750 | 800 |
Microwave output power | 750 | 750 (continuously adjustable) | 800 (continuous automatic adjustment of intelligent control) |
Microwave output | Continuous wave (adjustable by duty cycle) | Continuous wave (adjustable by duty cycle) | Continuous wave (intelligent automatic regulation) |
microwave frequencies | 2450Mhz±15Hz | ||
Continuous working time can be set (min) | 99h59min | 99h59min | 0-9999s / segment |
Temperature control mode | / | / | PID intelligent temperature control |
temperature measurement accuracy (℃) | / | / | ±0.2 |
Temperature control accuracy of (℃) | / | / | ≤1 |
maximum operation temperature | / | / | ≤250℃ |
display mode | Digital LED is displayed | Digital LED is displayed | LCD digital display |
Procedure temperature control section | / | / | 5 |
source | 220V / 50Hz 10A national standard | ||
Inner chamber size (mm) | 305*305*200 | 330*325*200 | 330*330*235 |
Overall dimensions (mm) | 485*410*325 | 520*420*410 | 400*510*470 |
