A high-pressure reactor, also known as a pressurized vessel, high-pressure reactor, or autoclave, is a sealed container designed specifically for conducting physical or chemical reactions under extreme conditions of high temperature and pressure.
A high-pressure reactor, also known as a pressurized vessel, high-pressure reactor, or autoclave, is a sealed container designed specifically for conducting physical or chemical reactions under extreme conditions of high temperature and pressure.
Unlike ordinary atmospheric pressure reaction vessels, high-pressure reaction vessels can withstand internal pressures of up to 30MPa (or even higher) and temperatures above 600°C by having thicker vessel walls, using high-strength alloy materials, and employing specialized sealing structures. These vessels are the core equipment for implementing key processes such as hydrogenation, polymerization, condensation, hydrothermal synthesis, and supercritical reactions in the fields of petrochemicals, new material synthesis, biotechnology, new energy, and defense research. They are hailed as the “power heart” of modern chemical industry.
Zhuoinstrument TGYF-B desktop magnetic mixing stainless steel, reactor technical parameters table | |||||
product model | TGYF-B-0.05L | TGYF-B-0.1L | TGYF-B-0.25L | TGYF-B-0.5L | TGYF-B-1L |
volume | 0.05L | 0.1L | 0.25L | 0.5L | 1L |
material quality | 304 / 316L stainless steel, Harbin alloy C276 | ||||
design pressure | 22MPa | ||||
design temperature | 350℃ | ||||
heating power | 1.5KW | ||||
Heating method | electrical heating | ||||
Sealing method | Magnetic rotation, static seal, type A | ||||
display mode | liquid-crystal display | ||||
Temperature control mode | PID intelligent temperature control | ||||
Temperature control accuracy | ±1℃ | ||||
speed of agitator | 0-1000rpm/min | ||||
Stir form | Magnetic stirring | ||||
heating power | 0.6KW | 0.6KW | 0.8KW | 1.5KW | 1.5KW |
sample connection | ∅4 | ∅4 | ∅4 | ∅4 | ∅4 |
air intake | ∅4 | ∅4 | ∅4 | ∅4 | ∅4 |
vent | ∅4 | ∅4 | ∅4 | ∅4 | ∅4 |
Temperature measurement mouth | ∅4 | ∅4 | ∅4 | ∅4 | ∅4 |
Pressure gauge mouth | ∅4 | ∅4 | ∅4 | ∅4 | ∅4 |
outline dimension (mm) | 310*370*525 | 310*370*525 | 330*330*525 | 350*370*570 | 320*460*570 |
control section | ① Speed adjustment, ② temperature control (program control can be customized), ③ temperature display, ④ speed display, | ||||
Pipe mouth part | 1. Gas port needle type valve (equipped with air inlet pipe that can meet the connection of hydrogen, nitrogen and oxygen) 2, the vent outlet with needle type valve 3. Liquid port pin valve with kettle bottom tube (for sampling or discharging) 4. Pressure safety explosion-proof port with pressure gauge and blasting valve (explosion-proof plate) 5, the temperature measuring port with protection pipe with platinum resistance | ||||
Zhuocheng instrument TGYF-C desktop magnetic mixing stainless steel, technical parameters of the reactor | |||||
product model | TGYF-C-0.05L | TGYF-C-0.1L | TGYF-C-0.25L | TGYF-C-0.5L | TGYF-C-1L |
volume | 0.05L | 0.1L | 0.25L | 0.5L | 1L |
material quality | 304 / 316L stainless steel, Harbin alloy C276 | ||||
design pressure | 22MPa | ||||
design temperature | 350℃ | ||||
Heating method | electrical heating | ||||
Sealing method | Magnetic rotation, static seal, type A | ||||
display mode | liquid-crystal display | ||||
Temperature control mode | PID intelligent temperature control | ||||
Temperature control accuracy | ±1℃ | ||||
speed of agitator | 0-1000rpm/min | ||||
power of motor | 40W | 40W | 40W | 70W | 70W |
Stir form | Magnetic coupling stirring | ||||
heating power | 0.6KW | 0.6KW | 0.8KW | 1.5KW | 1.5KW |
sample connection | ∅4 | ∅4 | ∅4 | ∅4 | ∅4 |
air intake | ∅4 | ∅4 | ∅4 | ∅4 | ∅4 |
vent | ∅4 | ∅4 | ∅4 | ∅4 | ∅4 |
Temperature measurement mouth | ∅4 | ∅4 | ∅4 | ∅4 | ∅4 |
Pressure gauge mouth | ∅4 | ∅4 | ∅4 | ∅4 | ∅4 |
cooling water outlet and inlet | ∅4 | ∅4 | ∅4 | ∅4 | ∅4 |
outline dimension (mm) | 350*330*590 | 350*330*590 | 350*330*590 | 350*330*590 | 320*460*650 |
control section | ① Speed adjustment, ② temperature control (program control can be customized), ③ temperature display, ④ speed display, | ||||
Pipe mouth part | 1, mixing port magnetic coupler 2, gas phase port needle valve (equipped with inlet pipe can meet the connection of hydrogen, nitrogen, oxygen various applicable gas) 3, vent port needle valve 4, liquid port needle valve with kettle internal bottom tube (sampling or feeding) 5, pressure safety explosion-proof port with pressure gauge and blasting valve (explosion-proof plate) 6, temperature measuring port with protection pipe with platinum resistance | ||||
